Spring MVC源码解析：HandlerMapping处理器映射器详解

创作时间:

作者:

@小白创作中心

Spring MVC源码解析：HandlerMapping处理器映射器详解

引用

CSDN

https://blog.csdn.net/Lxn2zh/article/details/128545470

本文将深入分析Spring MVC框架中的HandlerMapping处理器映射器的源码实现。从概念到具体实现，逐步展开，帮助读者理解Spring MVC的请求处理流程。

系列文章目录

springmvc源码之Web上下文初始化
springmvc源码之DispatcherServlet前端控制器
springmvc源码之HandlerMapping处理器映射器

HandlerMapping处理器映射器

HandlerMapping的主要作用是根据请求（request）找到相应的处理器（Handler）和拦截器（Interceptors）。其核心方法如下：

HandlerExecutionChain getHandler(HttpServletRequest request) throws Exception;

实现类

HandlerMapping帮助DispatcherServlet进行web请求的url到具体处理类的匹配，用来根据请求的url查找Handler，内部维护的Map<String, Object>映射，springmvc提供了不同的映射器实现不同的映射方式，例如：配置文件方式，实现接口方式，注解方式等

private final Map<String, Object> handlerMap = new LinkedHashMap<String, Object>();

Spring自带了多个处理器映射实现：

BeanNameUrlHandlerMapping：根据控制器Bean的名字将控制器映射到URL
ControllerBeanNameHandlerMapping：与BeanNameUrlHandlerMapping类似
ControllerClassNameHandlerMapping：通过使用控制器的类名作为URL基础将控制器映射到URL
DefaultAnnotationHandlerMapping：将请求映射给使用@RequestMapping注解的控制器和控制器方法
SimpleUrlHandlerMapping：使用定义在Spring应用上下文的集合将控制器映射到URL
RequestMappingHandlerMapping：SpringMVC3.1新增的，在springMVC3.1之前，DefaultAnnotationHandlerMapping会在类级别上选中一个控制器，然后通过AnnotationMethodHandlerAdapter定位到具体要调用的方法；而在SpringMVC3.1之后，这些操作全都放生在RequestMappingHandlerMapping中，从类级别和方法级别的@RequestMapping注解中获取到路径映射信息，使得在HandlerInterceptor中获取到的处理器肯定是一个HandlerMethod类型

配置

<!-- 开启注解 -->
<mvc:annotation-driven/>
<bean id="defaultAnnotationHandlerMapping"
      class="org.springframework.web.servlet.mvc.annotation.AnnotationMethodHandlerAdapter"/>

<mvc:annotation-driven/>配置的作用：

自动注册RequestMappingHandlerMapping、RequestMappingHandlerAdater、ExceptionHandlerExceptionResolver三个bean
支持使用ConversionService实例对表单参数进行类型转换
支持使用@NumberFormatannotation、@DataTimeFormat注解完成数据类型的格式化
支持使用@Vaild注解对JavaBean实例进行JSR 303验证
支持使用@RequestBody和@ResponseBody注解

RequestMappingHandlerMapping源码

由于一般都使用<mvc:annotation-driven/>进行配置，所以就以RequestMappingHandlerMapping为例进行讲解

创建

首先进行创建

其实现了ApplicationContextAware，所以需要执行setApplicationContext

// 调用链路 org.springframework.context.support.ApplicationObjectSupport#setApplicationContext ——>org.springframework.context.support.ApplicationObjectSupport#initApplicationContext(org.springframework.context.ApplicationContext) -->org.springframework.web.servlet.handler.AbstractHandlerMapping#initApplicationContext
// org.springframework.web.servlet.handler.AbstractHandlerMapping#initApplicationContext
protected void initApplicationContext() throws BeansException {
  // 扩展interceptors的方法，空实现
   extendInterceptors(this.interceptors);
  // 将容器中的所有MappedInterceptor类型的bean添加到mappedInterceptors中
   detectMappedInterceptors(this.adaptedInterceptors);
  // 初始化Interceptor，将interceptors中的对象添加到adaptedInterceptors中
   initInterceptors();
}

其实现了InitializingBean，需要执行afterPropertiesSet

// org.springframework.web.servlet.handler.AbstractHandlerMethodMapping#afterPropertiesSet
public void afterPropertiesSet() {
   initHandlerMethods();
}
// org.springframework.web.servlet.handler.AbstractHandlerMethodMapping#initHandlerMethods
protected void initHandlerMethods() {
        // 拿到容器中的bean，筛选出Handler
        String[] beanNames = (this.detectHandlerMethodsInAncestorContexts ?
                BeanFactoryUtils.beanNamesForTypeIncludingAncestors(getApplicationContext(), Object.class) :
                getApplicationContext().getBeanNamesForType(Object.class));
        for (String beanName : beanNames) {
            if (!beanName.startsWith(SCOPED_TARGET_NAME_PREFIX)) {
                Class<?> beanType = null;
                try {
                    beanType = getApplicationContext().getType(beanName);
                }
                catch (Throwable ex) {

                }
        // (AnnotatedElementUtils.hasAnnotation(beanType, Controller.class) ||AnnotatedElementUtils.hasAnnotation(beanType, RequestMapping.class));  判断
                if (beanType != null && isHandler(beanType)) {
          // 将访问地址、Method进行映射
                    detectHandlerMethods(beanName);
                }
            }
        }
        handlerMethodsInitialized(getHandlerMethods());
    }

访问

在进行访问的时候会通过org.springframework.web.servlet.DispatcherServlet#getHandler方法来遍历handlerMappings

HandlerExecutionChain handler = hm.getHandler(request);

来调用HandlerMapping的getHandler方法

// org.springframework.web.servlet.handler.AbstractHandlerMapping#getHandler
public final HandlerExecutionChain getHandler(HttpServletRequest request) throws Exception {
  // 找到Handler，根据地址找到对应的方法
   Object handler = getHandlerInternal(request);
   if (handler == null) {
      handler = getDefaultHandler();
   }
   if (handler == null) {
      return null;
   }
   // Bean name or resolved handler?
   if (handler instanceof String) {
      String handlerName = (String) handler;
      handler = getApplicationContext().getBean(handlerName);
   }
  // 为handler生成执行链，即添加interceptor
   HandlerExecutionChain executionChain = getHandlerExecutionChain(handler, request);
   if (CorsUtils.isCorsRequest(request)) {
      CorsConfiguration globalConfig = this.globalCorsConfigSource.getCorsConfiguration(request);
      CorsConfiguration handlerConfig = getCorsConfiguration(handler, request);
      CorsConfiguration config = (globalConfig != null ? globalConfig.combine(handlerConfig) : handlerConfig);
      executionChain = getCorsHandlerExecutionChain(request, executionChain, config);
   }
   return executionChain;
}

getHandlerInternal

// org.springframework.web.servlet.handler.AbstractHandlerMethodMapping#getHandlerInternal
protected HandlerMethod getHandlerInternal(HttpServletRequest request) throws Exception {
   String lookupPath = getUrlPathHelper().getLookupPathForRequest(request);
   if (logger.isDebugEnabled()) {
      logger.debug("Looking up handler method for path " + lookupPath);
   }
   this.mappingRegistry.acquireReadLock();
   try {
      HandlerMethod handlerMethod = lookupHandlerMethod(lookupPath, request);
      if (logger.isDebugEnabled()) {
         if (handlerMethod != null) {
            logger.debug("Returning handler method [" + handlerMethod + "]");
         }
         else {
            logger.debug("Did not find handler method for [" + lookupPath + "]");
         }
      }
      return (handlerMethod != null ? handlerMethod.createWithResolvedBean() : null);
   }
   finally {
      this.mappingRegistry.releaseReadLock();
   }
}

getHandlerExecutionChain

protected HandlerExecutionChain getHandlerExecutionChain(Object handler, HttpServletRequest request) {
   HandlerExecutionChain chain = (handler instanceof HandlerExecutionChain ?
         (HandlerExecutionChain) handler : new HandlerExecutionChain(handler));
   String lookupPath = this.urlPathHelper.getLookupPathForRequest(request);
   for (HandlerInterceptor interceptor : this.adaptedInterceptors) {
      if (interceptor instanceof MappedInterceptor) {
         MappedInterceptor mappedInterceptor = (MappedInterceptor) interceptor;
         if (mappedInterceptor.matches(lookupPath, this.pathMatcher)) {
            chain.addInterceptor(mappedInterceptor.getInterceptor());
         }
      }
      else {
         chain.addInterceptor(interceptor);
      }
   }
   return chain;
}

参考文献

HandlerMapping
